Xi'an Outdoor Garden Tools Co., Ltd.
7 Years
| Ask Lasest Price | |
| Brand Name : | Garrida |
| Model Number : | GR-40 |
| Certification : | CE |
| Price : | USD16.3-19.9/PC |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability : | 30000PCS/MONTH |
| Delivery Time : | 25-30DYAS |
Noted: This pump should not be used for petrol, flammable or low flash point liquids
Features
Self-priming, rotary electric vane pumps for the transfer of diesel fuel equipped with by-pass valve
Build-in overload motor protector
Pump Body: Cast-iron (Treated against corrosion and paint-finished)
Low power consumption
Liquid temperature: Up to 35°C
Dry-running of pump shall be prohibited
Compact size - easy to install, operation and maintenance
Safety and reliability
Specifications
Article Type: GR-40
Rated Power: 160W
Volt: DC12V/24V
Max.Pump rate: 40L/min
Max.height: 10m
Self-primming height: 5.0m
Pipe size: 3/4"
Speed: 3600r/min
Cable Length: 1.8m
Accessories: 2pcs fitting, 2pcs hose claps, 1pcs plastic check valve
Packing size:38*27.5*39cm/4pcs
Weight appro:16/14.5kg
20GP: 3200PCS
| Model | Voltage | Power | Head | Flow | Speed | outlet | cable | Self-priming | Qty/20” |
| GR-40 | DC12V/24V | 160W | 10m | 2400L/h | 3600/min | 3/4” | 2m | 5.0m | 3200pcs |
|
|
